WHY FOLLOW TRACKS WHEN YOU CAN MAKE YOUR OWN? EXPERIENCE THE “FOOT OUT, FLAT OUT” FUN OF FAT BIKE RIDING IN ANY SEASON. WHETHER YOU’RE TACKLING FRESH SNOW PACK OR DRIFTY SAND DUNES FOR DAYS, THE NEW YUKON WILL KEEP YOU RALLYING YOUR FAVORITE TERRAIN IN A WHOLE NEW WAY.
The incredible capability of the Yukon series will keep you conquering and grinning in all conditions. This feature-packed design offers a modern trail bike experience coupled with maximum control and floatation over the most ridiculous of surfaces. Its lightweight Aluxx SL-Grade frame tubeset and Advanced Composite grade fork featuring wide axle spacing (150/197mm [F/R] ) and a PressFit 121 bottom bracket, makes this modern fat bike agile and versatile. Its stabile and adjustable geometry, high volume 27.5”X 4.5” tire capability and ample clearances means you’ll never miss a day of riding again, no matter the season.
LOW CENTER OF GRAVITY PLAYFUL TRAIL BIKE
Sloping "low slung" front triangle design provides a low center of gravity for technical maneuvering with ease or countersink control in deep conditions.
MAXIMUM HEEL CLEARANCE WITH LOW Q-FACTOR
With a heavily swaged rear triangle including dropouts, seatstays and chainstays, this versatile design allows even warmest of riding boots to be worn, while the narrow Q-Factor crank specification provides a more natural feeling cycling experience.
CUSTOM WHEELBASE ADJUSTMENT AND TIRE SIZE FLEXIBILITY
The horizontal adjustable drop out system allows for +/- 15mm rear center length adjustment and tire sizing up 27.5 X 4.5” for maximum floatation to and a fun, playful ride.
NB! Snøbildene viser feil dekk.
|
Sizes |
S,M,L, XL |
|
Colors |
Black/Charcoal, Sand/Red |
|
Frame |
ALUXX SL-Grade Aluminum ( OLD 197mm, Tire Max. 27.5”x4.5"") Horizontal Adjustable Dropout System |
|
Fork |
Advanced-Grade Composite, 15x150 (fits up to 5.0 tire), Low-rider rack mounts & extra water bottle mounts. Rack & Fender eyelets |
|
Shock |
N/A |
|
Handlebar |
Giant Connect Trail, 780mm x 31.8mm |
|
Stem |
Giant Connect, 8 Degree |
|
Seatpost |
Giant Connect, 30.9mm(375mm S/ M ,400mm L/XL) |
|
Saddle |
Giant Contact (Neutral) |
|
Pedals |
N/A |
|
Shifters |
Shimano Deore, 1x10 Speed |
|
Front Derailleur |
N/A |
|
Rear Derailleur |
Shimano Deore, Shadow + |
|
Brakes |
Shimano MT201 [F] 180mm [R] 160mm, Hydraulic Disc |
|
Brake Levers |
Shimano MT201 |
|
Cassette |
Shimano Deore,11x42 |
|
Chain |
KMC X10 with Missing Link |
|
Crankset |
Pro-Wheel with steel 28t WAVE ring for narrow Q-Factor 208 |
|
Bottom Bracket |
PF121 |
|
Rims |
Giant FB27.5, 86mm inner width, Tubeless compatible, AV & PV ready |
|
Hubs |
F: GiantTracker 15x150, Sealed 2 Bearing, 15mm Thru-Axle Bolt R: Giant Tracker 12x197, Thru-Axle (Shimano Cassette) |
|
Spokes |
14-15-14G STEEL |
|
Tires |
Maxxis Colossus, 27.5x4.50, 120tpi, TR, EXO |
|
Extras |
PV Tubeless Valves |
