Model Name
|
Fathom E+ EX
|
|
Sizes
|
S, M, L, XL, XXL
|
|
Colors
|
|
|
Motor
|
SyncDrive Sport, 70Nm, powered by Yamaha
|
|
Battery
|
EnergyPak Smart 625
Giant EnergyPak Plus range extender compatible
|
|
Controls
|
RideControl Dash
|
|
Display
|
RideControl Dash, full color lcd screen
|
|
Chargers
|
EnergyPak 4A smart charger compact
|
|
Frame
|
ALUXX aluminum, Overdrive 1½ - 1?" head tube, 141mm Boost QR, ISS,
EnergyPak Plus Range Extender compatible, integrated KSA18 kickstand mount
|
|
Fork
|
SR Suntour XCR 34 Boost Air LOR 29, 120mm travel, Tapered 1½ - 1?"
steerer, lockout
|
|
Shock
|
n/a
|
|
Handlebar
|
Giant Connect TR Riser 31.8x690~780mm
|
|
Grip
|
Giant Tactal single lock-on
|
|
Stem
|
Giant Contact
|
|
Seatpost
|
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
|
|
Saddle
|
Giant Sport
|
|
Pedal
|
Aluminum Platform
|
|
Shifters
|
Shimano Deore 10-speed
|
|
Front Derailleur
|
n/a
|
|
Rear Derailleur
|
Shimano Deore, 10-speed, Shadow+
|
|
Brakes
|
Tektro HD-M280, hydraulic disc, 180mm
|
|
Brake Levers
|
Tektro HD-M280
|
|
Cassette
|
Shimano CS-M4100-10 11-46T 10-speed
|
|
Chain
|
KMC e.10 Sport, e-bike optimized
|
|
Crankset
|
FSA Comet E-Bike crank arm set
FSA MegaTooth Direct-mount 1X steel 36T
|
|
Bottom Bracket
|
n/a
|
|
Rims
|
Giant XCT 29 Tubeless Ready 25mm e-bike optimized
|
|
Hubs
|
Shimano MT410 Boost, Center-Lock, [F] 110x15, Shimano MT200-B [R] 141mm
OLD, QR
|
|
Spokes
|
Stainless steel
|
|
Tires
|
Maxxis Rekon Race 29 x 2.25", Wire Bead, Dual Compound 60TPI
|
|
Lights
|
Herrmans H-BLACK MR8
Axa BlueLine Steady E6 rear
|
|
Kickstand
|
KSA18 direct mount kickstand
|
|
Carrier
|
Giant Rack-It MIK
|
