Operating
System
|
Giant E+ System
|
|
Controls
|
Giant RideControl Ergo, Smart Assist automatic mode, 5
manual support levels, LED indicators
|
|
Display
|
N/A
|
|
Connectivity
|
Giant RideControl App enabled ANT+ wireless display
signal with e-bike profile
|
|
Battery
|
Giant EnergyPak 800Wh, 22700 Lithium cell technology
|
|
Compatible
|
Giant EnergyPak Plus 200Wh range extender compatible
|
|
Chargers
|
Giant EnergyPak 4A smart charger compact,
|
|
Motor
|
Giant (Yamaha) SyncDrive Pro2, 85Nm,PedalPlus 6-sensor
technology
|
|
Frame
|
ALUXX aluminum, Overdrive 1½ - 1.½" head tube,
148x12mm Thru-Axle,
|
|
integrated KS40 kickstand mount,
M10 Trailer/Sled mount
|
|
Fork
|
Manitou Mastodon Comp, 27.5", 100mm travel,
Expert Air, Absolute+ compression
|
|
Shock
|
-
|
|
Handlebar
|
Giant Contact TR 35x780mm
|
|
Grip
|
Giant XC Pro
|
|
Stem
|
Giant Contact SL 35mm (S-XL: 50mm)
|
|
Seatpost
|
Giant Contact Switch, adjustable dropper seatpost
MatchMaker remote
|
|
Saddle
|
Giant Contact Ergo trail
|
|
Pedal
|
Aluminum Platform
|
|
Shifters
|
Shimano Cues LinkGlide
|
|
Front Derailleur
|
-
|
|
Rear Derailleur
|
Shimano Cues, LinkGlide, 10-speed, Shadow+
|
|
Brakes
|
SRAM Code R, hydraulic 4-piston disc (180/180mm)
|
|
Brake Levers
|
SRAM Code R
(DB-CODE-R-B1)
|
|
Cassette
|
Shimano Cues, CS-LG300, 11-48T, 10-speed LinkGlide
|
|
Chain
|
KMC eGlide NP/BK, e-bike optimized
|
|
Chainring
|
Narrow/Wide steel 36T
|
|
Crankset
|
Forged Alumium crank arm set 165mm
|
|
Rims
|
Giant FT85C 27.5", alloy, disc (75mm inner), 28H,
AV & PV ready
|
|
Hubs
|
Giant XF02 [F] 15x150mm sealed bearing
|
|
Giant D919 [R] 12x197mm sealed bearing
|
|
Spokes
|
Stainless steel
|
|
Tires
|
Vee Tire Co. Avalanche, tubeless, studdable, folding,
27.5x4.5", SC compound, 120 TPI
|
|
Extras
|
|
