ARKIVMODELL FOR RESERVEDELER

FRAME     ALUXX SL-grade aluminum, 120mm FlexPoint suspension system

FORK     RockShox Recon RL, 130mm travel, Lockout, 110x15mm MaxleLite

SHOCK     RockShox Monarch RT, High Volume, 184x44mm, custom tuned

HANDLEBAR  Giant Connect TR Riser 31.8x780mm

STEM     Giant Contact

SEATPOST     Giant Contact Switch, dropper, 30,9mm (S:100/M:125/L:150/XL:170)

SADDLE     Giant Contact, Neutral

PEDALS     -

SHIFTERS  SRAM SX EAGLE SINGLE CLICK TRIGGER 12S BLK, W/ CLAMP (00.7018.386.000)

FRONT DERAILLEUR     -

REAR DERAILLEUR     SRAM SX EAGLE 12S LONG CAGE BLK (00.7518.122.000)

BRAKE FRONT     Shimano BL-MT501L+BR-MT520F

BRAKE REAR     Shimano BL-MT501R+BR-MT520R

CASSETTE     SRAM PG-1210 12S 11-50T BLK (00.2418.095.000)

CHAIN     SRAM SX EAGLE 124L W/PWR.LCK 12S GREY (00.2518.040.008)

CRANKSET     SRAM X-Sync Eagle 38T 104BCD chainring Praxis e-Cadet+ custom   forged crankarm set (Q-factor=168, S:160, M/L:165, XL:170)

BOTTOM BRACKET  N/A

RIMS     Giant XCT 29 Tubeless Ready 25mm e-bike optimized

HUBS     Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, [F] 110x15 [R]   148x12mm Thru-axle

SPOKES     Sapim E-Lite [r] Race [f], e-bike optimized

TIRES     Maxxis Ardent 29x2.4" foldable, 60tpi Dual Compound EXO, Tubeless   Ready

EXTRAS     Giant EnergyPak 6A Smart charger Tubeless kit (liquid, valves, levelrs,   manual, tool)

MOTOR  Giant Yamaha SyncDrive Pro

SENSORS     Giant PedalPlus 6-sensor technology

DISPLAY     Giant RideControl ONE

BATTERY     Giant EnergyPak Smart 500, 36V 13.8Ah integrated Lithium-Ion
